SPECIFICATION FOR STANDARD AMF PANEL 15 KVA Cubicle type, base mounting control panel with hinged doors, undrilled bottom gland plate, AL. Bus Bar and accommodating the following: SWITCH GEARS: 32A, 4 Pole Contactor for ALTERNATOR with Thermal O/L relay 32A, 4 Pole Contactor for MAINS (OPTIONAL) BACK-UP PROTECTION: MCB for short circuit protection MICROPROCESSOR BASED AMF MODULE INCORPORATING: Functions: Supply Failure Timer Restoration Timer 3 Impulse automatic engine Start / Stop logic & engine fails to start lockout Mains / Generator Voltage & Frequency Sensing. Multifunctional Meter with Scrolling Readings for Water Temperature/ Oil Pressure Voltage / Ampere/ Frequency / kW / kVA Running-hour counter Electronic kWH meter (Counter Display) Current Transformers Indications (LED): DG ON, Load on DG Mains ON, Load on Mains, Battery Charger ON Push Buttons (AMF MODULE BY PASS MODE) Engine START / STOP ( Provided on Engine Controller ) Generator Contactor CLOSE / TRIP Mains Contactor CLOSE / TRIP (If provided) Fault ACCEPT / RESET BATTERY CHARGER: SMPS Based Unit with inbuilt Auto/Manual & Float/Boost Facility DC Voltmeter & Ammeter (Separate) PLHO / 0712/RKS/ASN
